What Is Induction Brazing?

Brazing is a process for joining two metals with a filler material that melts, flows and wets the metals’ surfaces at a temperature that is lower than the melting temperature of the two metals.

What Is Induction Brazing?

Brazing is a process for joining two metals with a filler material that melts, flows and wets the metals’ surfaces at a temperature that is lower than the melting temperature of the two metals.

brazing-thumb

Benefits of Brazing with Induction

Induction generates an electromagnetic field in a work coil that induces currents in the conductive material of a workpiece placed within or near the coil. Friction from these currents elevates the temperature of the workpieces and filler to be brazed.

Induction brazing delivers precise, localized heat, increases production rates with faster heating cycles and reduces defect rates with repeatable, reliable heating, eliminating variability from part to part, while maintaining metallurgical characteristics of the individual metals. No need for open flame or a batch process.



Free Induction brazing Application Notes


image: Brazing Steel Assemblies (hydraulics)Brazing Steel Assemblies (hydraulics)

A custom-designed single position multiple-turn oval split helical coil was built to generate the required heating for this brazing application.

image: Brazing an Aluminum Tube AssemblyBrazing an Aluminum Tube Assembly

A custom-designed single position multiple-turn pancake coil was built to generate the required heating for this brazing application. Initial tests were conducted to optimize power delivery to the assembly

image: Brazing a Carbide and Steel AssemblyBrazing a Carbide and Steel Assembly

A custom-designed single position multiple-turn helical coil was built to generate the required heating for this brazing application. Initial tests were conducted to optimize power delivery.

image: Brazing Copper Tubes for a Solar Industry ApplicationBrazing Copper Tubes for a Solar Industry Application

A custom-designed single position multiple-turn split-helical coil was built to generate the required heating for this brazing application.

image: Brazing FishhooksBrazing Fishhooks

A custom designed single position multiple-turn helical coil was built to generate the required heating for the application.

image: Brazing Copper BussbarsBrazing Copper Bussbars

A custom-designed single position multiple-turn helical coil was built to generate the required heating for the application.

image: Brazing a Copper Tube & Brass FittingBrazing a Copper Tube & Brass Fitting

A custom-designed single position multiple-turn U-shape coil was built to generate the required heating for this brazing application.

image: Brazing Copper and Brass ValvesBrazing Copper and Brass Valves

To braze various copper and brass assemblies for a valve manufacturer; they are looking to replace their torch heating process with induction

image: Brazing Steel Fittings & Tubes (Hydraulics)Brazing Steel Fittings & Tubes (Hydraulics)

Braze steel fittings and tubes in an atmosphere to make hydraulic fittings within a targeted heating time of under 150 seconds.

image: Brazing Both Ends of a Steel AssemblyBrazing Both Ends of a Steel Assembly

The client wanted to braze both ends of the part concurrently within their time requirements. Induction met the client’s time requirements and is often faster than other heating methods. With induction there is no open flame and with induction’s instant on/off capabilities, it introduces less heat into the work environment.

image: Brazing Copper and Brass Fittings (Flange)Brazing Copper and Brass Fittings (Flange)

How to braze copper tubes and a steel plate for a brazing application; while this is a new process for the client, they also tested the process with a torch

image: Steel Nozzle Assembly (Aerospace)Steel Nozzle Assembly (Aerospace)

Where you can struggle with repeatability with an oven and torch, induction brazing is a more repeatable process. With induction heating, there is no open flame and the benefit of instant on/off capabilities. This introduces less heat into the work environment.

image: Brazing Brass and Copper NozzlesBrazing Brass and Copper Nozzles

To braze copper and brass samples for an application in the aerospace industry, induction heating was used in place of a previously used torch. Induction brazing allows more consistent, higher quality parts.du

image: Brazing a Steel Part for the Aerospace IndustryBrazing a Steel Part for the Aerospace Industry

A custom-designed multiple-turn helical coil was built to generate the required heating for a steel cable for the aerospace industry. Induction brazing was used to heat a steel part for a brazing application.

image: Brazing, De-brazing Carbide, Steel PlatesBrazing, De-brazing Carbide, Steel Plates

A custom-designed special multiple-turn helical coil was built to generate the required heating to heat a carbide and steel plate assembly for a brazing and de-brazing application in the oil and gas industry.

image: Brazing Brass Assembly; Sink ManufacturerBrazing Brass Assembly; Sink Manufacturer

To heat brass assemblies for a brazing application, the client, who manufactures sink products had been using a torch. Induction heating heated the assembly to temperature and better met the client’s time requirements.

image: Brazing a Copper Tube and Steel PlateBrazing a Copper Tube and Steel Plate

In order to braze copper, a custom-designed single position multiple-turn helical coil was built to generate the required heating for the tube-to-plate brazing application. Initial tests were conducted to optimize the power delivered to the part. Repeatability was a top priority for this client.

image: Brazing a Nickel Pin and a Nickel WireBrazing a Nickel Pin and a Nickel Wire

A client had been using flame heating to braze a nickel pin and a braided nickel wire. The end-product is a heater assembly. Using induction improved joint quality compared to using flame heating.

image: Brazing a Carbide Tip and Magnetic Steel TubeBrazing a Carbide Tip and Magnetic Steel Tube

To braze carbide inserts into magnetic steel tubes, an inconsistent torch process was replaced with induction brazing equipment. In this application, quality rather than speed was the top priority.b

image: Brazing a Steel and Carbide AssemblyBrazing a Steel and Carbide Assembly

To braze a steel and carbide assembly to create a mining bit for the oil and gas industry, this client replaced their torch process with the repeatable and flameless induction brazing technique.

image: Braze a Copper Tube and Brass Fitting (fuel containment)Braze a Copper Tube and Brass Fitting (fuel containment)

How to braze copper using a custom-designed single position multi-turn helical coil built to generate the required heating for the copper brazing application.

image: Brazing a Copper Strip AssemblyBrazing a Copper Strip Assembly

The client requested a system that would meet their time objectives which the EKOHEAT easily did, boosting the client's throughput.

image: Induction brazing a Steel Tube with External Wire BraidInduction brazing a Steel Tube with External Wire Braid

The coil selected is not only capable of induction heating the steel 7/8/22 mm tube, but also a smaller tube that the client needs to heat.

image: Brazing, De-Brazing Diamond Carbide InsertsBrazing, De-Brazing Diamond Carbide Inserts

Heat steel cutting bits with diamond-carbide inserts for brazing and de-brazing; the end products are cutting tools

image: Brazing a steel and carbide dental assemblyBrazing a steel and carbide dental assembly

This configuratoin achieved the client's objective. The channel coil - specially designed by THE LAB at Ambrell- was critical to the application's success.

image: Brazing a brass tube and flange; torch replacementBrazing a brass tube and flange; torch replacement

Application engineers determined placing a turn that is targeted to the tube inside the part would optimize heating for this application. This heats the tube while the flange is being heated enabling both parts to achieve the required temperature concurrently.

image: Brazing a magnetic steel cutting tool with inductionBrazing a magnetic steel cutting tool with induction

Induction heating rapidly heats the steel parts to the required temperature, especially with the EKOHEAT's Auto Tap feature. The Ambrell Applications Lab used their expertise to create the right solution for the system and the system hardware.

image: Brazing a steel and copper strip to carbideBrazing a steel and copper strip to carbide

Induction heating of the steel took less than 30 seconds, is highly repeatable and there is no open flame, clear benefits over flame heating. it a safer method of heating than torch heating

image: Induction brazing a rectangular steel partInduction brazing a rectangular steel part

Induction heating of the steel took 30 seconds (or less), which can't be matched when using a torch. This client was using an old induction system from another vendor, and the Ambrell system provided considerably faster heating

image: How to braze a copper tubeHow to braze a copper tube

The client had been using a torch, which took 50 seconds instead of 30; induction brazing the copper increased repeatability and in turn boosted part quality. Also, there is no open flame which makes it a safer method of heating than torch heating

image: Copper block & carbide; contact assemblyCopper block & carbide; contact assembly

Induction completed the carbide brazing process more rapidly than an oven, delivering heat exactly where it's needed, operating instant on/instant off

image: Induction heating steel coupons and carbide cutters for brazing and de-brazingInduction heating steel coupons and carbide cutters for brazing and de-brazing

The first coupon that was heated had a 16 mm (0.63) diameter cutter, so removal of the cutter was the objective. The part was coated in black flux and inserted into the coil...

image: Brazing aluminum adaptors to the end of aluminum tubesBrazing aluminum adaptors to the end of aluminum tubes

To increase production, a multi-position coil was recommended so multiple parts could be heated while maintaining a cycle time of 55 seconds, delivering consistent joint quality, which a torch often doesn't deliver.

image: Brazing a nickel sleeve to a copper mastBrazing a nickel sleeve to a copper mast

To heat a nickel sleeve and a copper mast for a brazing application to create a pitot tube for the aerospace industry

image: Brazing a brass screw cap and a steel tubeBrazing a brass screw cap and a steel tube

Induction heating enables brazing the cap and tube to be completed at a rate of 15 seconds per part while delivering consistent joint quality in a safer environment which a torch often can't offer...

image: Brazing a stainless steel fitting to a stainless steel capillary tubeBrazing a stainless steel fitting to a stainless steel capillary tube

Induction enables consistent joint quality in about 35 seconds, which a torch often doesn't deliver; in this case this is the primary reason for switching to induction

image: Brazing a steel coupler and a steel wireBrazing a steel coupler and a steel wire

Induction heating enabled the brazing process to be completed within 30 seconds. The client was using a torch, and induction offers superior repeatability with no open flame and delivering heat only where it's required...

image: Brazing brass tube and fitting assembliesBrazing brass tube and fitting assemblies

The brass tubes and fittings heated to required temperature far more quickly than with customer's torch method, resulting in improved part quality and introducing less heat into the production environment...

image: Brazing carbide tips to a steel cutterBrazing carbide tips to a steel cutter

The cutter was held in a vice and the coil was presented to heat the assembly. A ceramic rod was used to press the carbide tip onto steel cutter during brazing.

image: Brazing a copper tube assemblyBrazing a copper tube assembly

The proposed system is capable of heating a wide variety of tube assemblies, is light enough to be used on a cart and is able to meet the client's time/productivity objectives

image: Brazing a brass tube assembly (valve manufacturing)Brazing a brass tube assembly (valve manufacturing)

With the recommended coil configuration, the cycle time turned out to be 25% less than what the client was targeting, resulting in increased production efficiency; a good braze joint was formed, and induction's consistency and repeatability proved valuable

image: How to braze three copper tubes to create a four-way valveHow to braze three copper tubes to create a four-way valve

Due to the use of a higher power system, speed expectations were exceeded and improved over the client's previous method, which was torch heating. A good copper braze joint was formed, and induction's consistency and repeatability proved valuable. Induction brazing doesn't employ an open flame, which results in a safer work environment

image: Brazing copper tubes to a brass manifold blockBrazing copper tubes to a brass manifold block

The proposed process met the client's time objective, and is faster than oven heating.

image: Brazing copper and brass valve assemblies (HVAC)Brazing copper and brass valve assemblies (HVAC)

The copper tube (1/8/3.2mm) is inserted into the flared copper tube (1/4/6.4mm). Two braze rings are placed on the copper tubes and the power is applied....

image: Brazing steel drill bits (aerospace)Brazing steel drill bits (aerospace)

The client wanted to heat three parts concurrently, and this process allowed up to five parts to be heated concurrently...

image: Brazing steel flange and shaft assemblies (aerospace and automotive applications)Brazing steel flange and shaft assemblies (aerospace and automotive applications)

Induction brazing is a repeatable process that isn't as labor intensive as a flame often is. The process can heat the assembly rapidly and more energy-efficiently than a torch without the safety risks that come with an open flame

image: Brazing two fittings and a helical tube to create a mountBrazing two fittings and a helical tube to create a mount

The client had been using a torch, and was dealing with inconsistent results that impacted part quality. Induction heats the assembly more quickly than the torch..

image: Brazing tubes and fittings for an air conditioning unit for the off-road marketBrazing tubes and fittings for an air conditioning unit for the off-road market

Clients were using an oven, and because the whole part was being heated and essentially annealed, it created problems with the part. Induction only heats the braze area, and resolves that issue...

image: Brazing a steel and brass immersion heating elementBrazing a steel and brass immersion heating element

Induction results in faster heating than a torch with faster, multipart heating to increase output...

image: Brazing an aluminum assembly for a bicycle manufacturing applicationBrazing an aluminum assembly for a bicycle manufacturing application

For this aluminum bicycle tube brazing application, induction heating delivers more repeatable and consistent results, while cutting client's heating time in half when compared to using a torch...

image: Brazing a magnetic steel tube and steel mating assemblyBrazing a magnetic steel tube and steel mating assembly

Heating a 0.437 (11.1) in(mm) outside diameter magnetic steel tube and steel mating assembly to temperature for a brazing application to create an oil tube for the railroad industry...

image: Brazing an aluminum manifold [air conditioning]Brazing an aluminum manifold [air conditioning]

Precise, repeatable heating: The client wanted more precise and repeatable heating than a torch could deliver, which induction was able to achieve..

image: Brazing a steel tube and fitting to create an automotive valveBrazing a steel tube and fitting to create an automotive valve

Customer's client was unhappy with the results from MIG welding, which drove them to look at induction as an alternative process. Induction heating proved to be a fast, repeatable heating method for the application...

image: Brazing a carbide ball to a spring to create a part that controls the armature position in a motorBrazing a carbide ball to a spring to create a part that controls the armature position in a motor

To heat a tungsten carbide ball and steel rod that acts as a spring to 1300 °F (704 °C) within five seconds for a brazing application to create a part that governs the armature position in a motor...

image: Brazing a steel rod and sensor housing assemblyBrazing a steel rod and sensor housing assembly

To heat a steel rod and housing to 1400 °F (760 °C) within 30 seconds for a brazing application to create an assembly for a sensor...

image: Heat a steel block with a cutout for carbide for a brazing applicationHeat a steel block with a cutout for carbide for a brazing application

Induction delivers improved quality and repeatability; client was using a torch and induction offered more precise, repeatable heating. In addition, this allowed the client to achieve the targeted heating time of 60 seconds, faster than what the torch could deliver...

image: Brazing a copper elbow tube assemblyBrazing a copper elbow tube assembly

In this copper brazing process, induction offers more precise, repeatable heating than current flame process...

image: Brazing copper tubing and brass fittings for aerospace partsBrazing copper tubing and brass fittings for aerospace parts

Induction heating achieves superior process repeatability when compared to a brazing torch and a more predictable aerospace parts which enhances quality..

image: Brazing a steel tube and fitting assemblyBrazing a steel tube and fitting assembly

Induction heating is used to braze a steel connector onto a steel tube to create a hydraulic component. ...

image: Brazing stainless steel medical tool parts into a couplingBrazing stainless steel medical tool parts into a coupling

Induction heating is used to achieve client's goal to braze both stainless steel parts as quickly as possible with maximum repeatability...

image: Brazing steel tube fittingsBrazing steel tube fittings

A tube assembly is heated to the desired braze temperature in 20-25 seconds, which achieves the client's targeted cycle time of less than 30 seconds...

image: Brazing a magnetic steel rotor assemblyBrazing a magnetic steel rotor assembly

Induction is proposed to replace a hand-operated flame process requiring operator training and expertise. Induction heating delivers a precise, repeatable and reliable process. Improved joint quality is coupled with simplified operation...

image: Brazing carbide insert to steel pipe gripper chuckBrazing carbide insert to steel pipe gripper chuck

Induction heating is proposed to braze carbide inserts into steel blocks in the assembly of pipe gripper chuck. To replace a hand/flame process, delivering significant reduction in per-part cycles...

image: Brazing a copper pipe assembly seamBrazing a copper pipe assembly seam

The customer is seam brazing copper pipes together. They will reduce the brazing of the seam down to 15-30 seconds.This customer is currently using a torch, but is not getting uniform quality

image: Brazing a pressure switch base assemblyBrazing a pressure switch base assembly

Induction heating provides hands-free heating that involves no operator skill for manufacturing, even distribution of heating precise and controllable heat

image: Brazing brass and steel for valves and end plugsBrazing brass and steel for valves and end plugs

The customer is currently using a torch to complete the braze joints. They wish to improve repeatability for a better process.

image: Brazing temperature sensor assembliesBrazing temperature sensor assemblies

A five-turn two-position helical coil is used for this brazing application. Each coil acts individually and the coils are not designed to heat simultaneously...

image: Brazing Copper Tubes to a Braided Stainless Steel HoseBrazing Copper Tubes to a Braided Stainless Steel Hose

Customer is currently using flame and a highly paid operator to complete this application. With an induction system, the customer can save approximately $20,000/year in operator cost alone, not factoring in any energy savings.

image: Brazing two aluminum pipes to an aluminum evaporator coreBrazing two aluminum pipes to an aluminum evaporator core

The customer is replacing a flame process which can burn away the thin flange at the joint area and create scrap parts. By switching to induction for this application the customer is decreasing their scrap parts and also increasing their quality and production rate...

image: Brazing brass bellow assemblies for pneumatic regulatorsBrazing brass bellow assemblies for pneumatic regulators

Customer is replacing flame with induction to braze/solder these parts. While they are not looking to increase their production, they are looking for a repeatable and reliable process...

image: Brazing a stainless steel shaft to a carbide for a digger used in miningBrazing a stainless steel shaft to a carbide for a digger used in mining

A three turn helical coil is used to braze the carbide to the shaft. The steel shaft is fluxed and the braze shim placed on top. The carbide tip is fluxed and placed on top of the shim, lining up the countersunk hole in the carbide. The hole is not fluxed because the flux outgases and causes the carbide to build up pressure and attempt to repel from the shaft...

image: Brazing a small gas delivery assembly used to manufacture needlesBrazing a small gas delivery assembly used to manufacture needles

This is a new part for the customer and they are developing the manufacturing process for it. The customer is interested in using induction heat for their process because they are looking for finished parts which are clean and not contaminated by any flux material. By using induction to braze the part and by doing the braze under a hydrogen atmosphere, the customer can produce brazed parts with no oxidation...

image: Brazing copper and steel tube combinations for refrigeration and air conditioningBrazing copper and steel tube combinations for refrigeration and air conditioning

Customer is currently using flame brazing in a large facility for this application and will gain safety benefits with induction such as no hazardous fumes or open flames...

image: Brazing a spray bar assembly used for powder coatingBrazing a spray bar assembly used for powder coating

Customer is currently outsourcing this application. By bringing in-house they will save on inventory build-up, transportation cost, time-to-customer and money. Customer found Ambrell on the web and liked the idea that Ambrell's application lab can prove capability before purchasing.....

image: Brazing vertical copper bars to a copper slip ring for refurbishing large motor assembliesBrazing vertical copper bars to a copper slip ring for refurbishing large motor assemblies

A three-turn helical coil is used to heat the slip ring. Power is applied for 25 minutes to bring the ring up to brazing temperature. The slip ring is then held at temperature as the self locating 52 vertical bars are brazed into place...

image: Brazing copper cable and block assembly for generator repairsBrazing copper cable and block assembly for generator repairs

A three-turn helical combination channel coil is used to heat the assembly. The assembly is placed in the coil with a thin ceramic paper placed between the coil and copper assembly...

image: Brazing aluminum electrical lug assemblyBrazing aluminum electrical lug assembly

A five turn helical coil is used to braze the assembly. The parts are assembled and placed in the coil. Power is applied and a braze stick is used to braze the two parts in 25-30 seconds...

image: Brazing a stainless steel shaft to a carbide cone for a gripperBrazing a stainless steel shaft to a carbide cone for a gripper

A three-turn helical coil is used to braze the carbide to the stainless steel shaft. A silver solder washer is placed over the post on the shaft, the carbide is placed on the washer and flux is applied...

image: Brazing a copper pivot assemblyBrazing a copper pivot assembly

A three-turn helical coil is used to heat the base of the assembly. The copper uprights and two braze shims are placed in the grooves in the base and black flux is applied...

image: Brazing brass faucet assemblyBrazing brass faucet assembly

A two turn C shaped coil is used to braze the faucet assembly. The braze rings are placed at the joint, the parts assembled and fluxed...

image: Brazing a steel piston valve assemblyBrazing a steel piston valve assembly

A five turn pancake coil is used to braze the piston valve and steel plate. The assembly was heated for 10 minutes to flow the braze and join the two pieces...

image: Brazing a steel die into a wire drawing guideBrazing a steel die into a wire drawing guide

A two-turn helical coil is used for brazing the assembly. Two different bonding agents are tested for the brazing application. The first bonding agent used is braze paste. The assembly is heated to 1382 °F (750 °C) and is brazed in 45 seconds....

image: Braze a thin walled tube to a steel cap in a hydrogen atmosphereBraze a thin walled tube to a steel cap in a hydrogen atmosphere

A single turn helical coil is used to heat the quartz tube and the tube assembly. The tube assembly is held in place inside the quartz tube by a copper fixture and hydrogen is fed into the quartz tube...

image: Braze two positions on a stainless steel manifold simultaneouslyBraze two positions on a stainless steel manifold simultaneously

A dual six turn split helical coil is used to simultaneously braze the manifold...

image: Braze a carbide tip to steel cutting toolBraze a carbide tip to steel cutting tool

A split helical coil is used to heat the carbide & circular steel cutter evenly for the brazing application. The circular steel cutter is placed in a vise and the carbide and braze shim are placed onto the tooth...

image: Braze a mount lead to a ferrule in a PAR light bulb assembly for automobilesBraze a mount lead to a ferrule in a PAR light bulb assembly for automobiles

A split helical coil heats 2-3 ferrules at a time. The ferrules are filled with flux and the mount leads are placed inside the ferrules...

image: Heat a compacted litz wire bundle for strippingHeat a compacted litz wire bundle for stripping

A three turn helical coil is used for the wire stripping process. The litz wire bundle is placed in the coil for 3 seconds to strip the lacquer 0.75 (19mm) from the end of the bundle. The wire bundle is then scraped with a metal brush to remove the burnt lacquer...

image: Braze electrical contacts to brass and copper busBraze electrical contacts to brass and copper bus

A five turn split helical coil is used to heat the assembly. The parts are placed 90° to the coil between the top turn and second turn with braze shims and flux.

image: Braze a diamond carbide tip onto band saw bladeBraze a diamond carbide tip onto band saw blade

A single turn helical coil is used for this brazing process. The saw blade and diamond carbide tip are placed in the coil...

image: Braze a stainless steel braided hose to copper elbow for flexible hosingBraze a stainless steel braided hose to copper elbow for flexible hosing

A two turn helical coil is used to heat the braided hose assembly. Braze rings are placed...

image: Braze an end plug on a stainless steel car grillBraze an end plug on a stainless steel car grill

A three turn square shaped helical coil is used to heat the end of the grill. End plugs are inserted into the grill and the assembly is inserted into the coil for 30 seconds.

image: Brazing joint on pressurized heater connectorsBrazing joint on pressurized heater connectors

Brazing a joint between a copper lug and nickel plated copper pins on a pressurized heater connector.

image: Brazing steel mold for golf ball dimple insertBrazing steel mold for golf ball dimple insert

Induction heating provides a no-flame process with reliable, repeatable, non contact and energy efficient heat in minimal time.

image: Heat aluminum for brazing an automotive assemblyHeat aluminum for brazing an automotive assembly

A multi turn pancake coil is used to heat the joint between the aluminum tubing and boss. The joint heats to temperature in 1.5 minutes and the braze ring melts forming a clean brazed joint.

image: Brazing stainless steel orthodontic begg bracketsBrazing stainless steel orthodontic begg brackets

A two turn oblong helical coil is designed to heat the steel brackets which are sandwiched between the two pieces of graphite.

image: Brazing automotive tube assembliesBrazing automotive tube assemblies

A four turn split helical coil is used to heat the steel assembly to 1400°F (760°C) for 85 seconds. The coil design allows for the steel fitting to expand away from the steel tube which allows braze to flow through the joint.

image: Brazing carbide teeth to steel pipe jaw sectionBrazing carbide teeth to steel pipe jaw section

Induction heating provides hands-free heating that involves no operator skill for manufacturing, consistent, repeatable aesthetically pleasing brazes with even distribution of heating

image: Braze a refrigeration tube coil assemblyBraze a refrigeration tube coil assembly

Induction heating provides the ability to direct heat only to the required zone, coil geometry which allows for easy loading and unloading of finished parts and the ability of coil to be used with water bath process allows for stability of the o-ring

image: Brazing stainless steel tree injectorBrazing stainless steel tree injector

Induction heating provides even distribution of heating, even flow of braze alloy for an aesthetically pleasing bond and system flexibility allows for the same unit to be used for two different applications which is a cost saving.

image: Braze four copper bus bars togetherBraze four copper bus bars together

A three-turn helical coil is used to heat the assembly. Three braze shim preforms are placed between the plates and white flux is applied to the assembly

image: Brazing a carbide and steel shank for a plug guageBrazing a carbide and steel shank for a plug guage

Induction heating provides hands-free brazing which requires no special operator skills for manufacturing, precise, even heat is applied and is divided equally, between the shank and the carbide, providing an even flow of the braze alloy as the parts reach brazing temperatures.

image: Braze steel O-ring Face Seal fittings to a steel tubeBraze steel O-ring Face Seal fittings to a steel tube

A four-turn 2.75 inch (7.0 cm) ID helical coil is used for heating both the steel tube and the ORFS sleeve or the ORFS male connector.

image: Steel-carbide brazing cutting toolSteel-carbide brazing cutting tool

The body shim and carbide are cleaned and braze flux as applied to the entire surface of the assembly. The parts are placed together in the induction coil.

image: Brazing carbide to steel for a surgical deviceBrazing carbide to steel for a surgical device

Compared to a stick-fed flame braze heating, induction heating provides consistently higher quality joints. This is critical for medical applications.

image: Brazing a Plumbing Union in Tight QuartersBrazing a Plumbing Union in Tight Quarters

Induction provides a reliable braze joint obtained under limited-access conditions, energy is applied only to the joint; little energy is lost to surrounding parts and flame is not used; no bottled gasses required

image: Brazing a Brass Trap BlockBrazing a Brass Trap Block

induction heats only the material within the coil; no energy is wasted heating the surrounding materials and air; no flame or gasses required for heating

image: Brazing Faucet Components, AssembliesBrazing Faucet Components, Assemblies

Three helical coils are used separately to braze a range of provided parts. Parts are assembled with flux and a braze alloy and then heated.

image: Brazing Brass Fitting to Copper TubeBrazing Brass Fitting to Copper Tube

For larger copper tube assemblies, the same process is used, but the braze alloy is stick-fed to the joint to prevent the alloy from flowing out of the joint.

image: Brazing Carbide Tips to a Meat CutterBrazing Carbide Tips to a Meat Cutter

Due to the size of the induction coil, the process allows for precise placement of the carbides on the steel shanks

image: Brazing Copper Fittings to Refrigeration ValveBrazing Copper Fittings to Refrigeration Valve

With induction, energy is applied only to the zone to be heated heating of the joint/braze is uniform and repeatable

image: Brazing a Cutting Tool AssemblyBrazing a Cutting Tool Assembly

Two sets of parts are placed in the individual coils. Braze preforms are placed on the cone at the joint.

image: Brazing carbide rotary file to high speed steel shanksBrazing carbide rotary file to high speed steel shanks

A multi-turn helical coil is used. The part is heated to determine the time required to reach the desired temperature and required heat pattern. I

image: Brazing Diamond Drill InsertsBrazing Diamond Drill Inserts

Induction heating delivers reduced ring warping compared to furnace heating and decreased cycle time due to reduced ramp-up and cooldown times

image: Brazing a carbide shaft to steel tubeBrazing a carbide shaft to steel tube

Induction heating provides even, precise heat. Precise directed heat is required for the solder braze to flow evenly around the part to assure a good joint.

image: Brazing Brass Ship Fittings for Repair Brazing Brass Ship Fittings for Repair

The coil allows heating at the best possible efficiency which reduces the cycle time and the conducted heat along the brass tubes.

image: Brazing a Bourdon Tube Assembly Brazing a Bourdon Tube Assembly

To braze a thin copper oval tube to a brass fitting at 1400 ° F and to cap the other end of the copper tube with a brass plate.

image: Brazing Copper ‘T’ AssembliesBrazing Copper ‘T’ Assemblies

To heat copper ‘T’ assemblies to 1400(760) ºF(ºC) for brazing

image: Braze Copper Tube to Brass FittingBraze Copper Tube to Brass Fitting

To use induction heating to braze a copper tube to a brass fitting using a preform braze wire.

image: Brazing steel orthodontic partsBrazing steel orthodontic parts

A four turn helical coil is used to heat parts. Brazing paste is applied to orthodontic parts with a syringe...

image: Brazing an Eyeglass Frame AssemblyBrazing an Eyeglass Frame Assembly

Goal is to achieve quality braze joints on the nose bridge, brow bridge and nose piece.

image: Brazing Turbine Blades with NickelBrazing Turbine Blades with Nickel

To heat an inconel turbine blade in a vacuum to 2000°F and hold temperature for five minutes for a nickel brazing application.

image: Brazing steel dental tools Brazing steel dental tools

To heat a steel tip and shank assembly to 1300°F (704°C) within 3 seconds for brazing with induction heating instead of torch brazing.

image: Brazing Copper J Tube into FittingsBrazing Copper J Tube into Fittings

To braze a copper tube ( 3/8 in OD by 2-4 in long) into a 3/8 in fitting in less than 10 seconds.

image: Brazing Oil Suction Assembly with Copper Ring Brazing Oil Suction Assembly with Copper Ring

To heat an oil suction assembly (steel tubing and filter cap) to 1,850°F (1010°C) within 15 seconds for a brazing application.

image: Brazing Copper Tube AssembliesBrazing Copper Tube Assemblies

To heat a copper tube assembly in an inert atmosphere to 1450°F within 45 seconds for brazing without flux or acid wash clean-up.

image: Brazing Hydraulic Hose AssembliesBrazing Hydraulic Hose Assemblies

To heat a steel hydraulic hose fitting in an inert atmosphere to 2200°F within 7 seconds for brazing without any carbon buildup.

image: Brazing Stainless Steel Conduit to a Ferrule and Elbow AssemblyBrazing Stainless Steel Conduit to a Ferrule and Elbow Assembly

To heat a stainless steel conduit, ferrule and elbow assembly to 1400°F (760°C) within 20 seconds for brazing.

image: Brazing a heat-sensing probeBrazing a heat-sensing probe

A C-shaped steel susceptor is used to ensure even heating and for ease of loading and unloading the samples.

image: Brazing Carbide Tips on Drill BitsBrazing Carbide Tips on Drill Bits

A brazing temperature of 1900°F was reached through the use of a unique 4 turn helical coil. D

Steel Brazing Applications

Induction brazing is the ideal technique for joining steel parts where welding is not suitable. A well-designed induction brazed steel joint provides many benefits including part geometry integrity and lower part stress. Carbon and stainless steel have high resistivity – they couple well to induction energy and heat easily. However, they have poor thermal conductivity so the induction brazing of steel parts should not be rushed. With steel, it is important the heat is given time to soak through to the joint surface for proper flow and wetting out of the braze material.

Induction Brazing Copper, Steel and Brass

Induction brazing is an excellent method of joining parts made of dissimilar metals. Applications with mixed metal joining include steel-to-copper, steel-to-brass and brass-to-copper. With these materials, it’s all about timing. For a successful brazed joint between different metals it is critical that both metal surfaces reach the braze flow temperature at the same time as the joint. The induction heating solution must take into account the different thermal conductivities of the materials, and the time each material takes to get to the required temperature.

Can Induction Be Used to Heat Carbon Fibers?

Induction has been used for carbon fibers all along. It depends how the fibers are layered though. If they’re all in one direction, then the heating isn’t very good and it’s not viable. But if they are woven and have a crisscross pattern, then they form electrical current paths that can be utilized by induction. So the carbon fiber layout is vital.

Is Induction More Energy Efficient?

Induction heating efficiency is derived from the following: selective heating, energy produced directly inside the metal without the aid of a transfer medium, and the ability to insulate the hot part from losing its heat to the environment.

Must Coils be Custom Fitted to Workpieces?

A coil used to heat a 30in workpiece can certainly be used to heat a 10 in workpiece given the following two criteria. First there should be enough spare capability in the power supply to overcome the coupling loss to the 10 in workpiece in the larger coil. Second, the time to heat the smaller workpiece may be much longer given the poor coupling to the part.

Can Induction be Used to heat liquid flowing in tubes?

Yes, induction heating is routinely used to heat fluids flowing through metal tubes. Ambrell has provided solutions to numerous such applications.

Get 10 Brazing Application Notes

Brazing AppNotes thumb

We have collected 10 of THE LAB's most popular brazing application notes to help you understand the many ways induction heating can improve your precision brazing process.

Get 10 Copper Brazing Application Notes

Brazing Copper Volume 1

We have collected 10 of THE LAB's most popular copper parts brazing application notes to help you understand the many ways induction heating can improve your precision copper parts brazing process.

Four Ways To Contact Ambrell for Support

AMBRELL CORPORATION

1655 Lyell Avenue
Rochester, NY 14606
United States


Directions to Ambrell Corporation Directions

T: +1 585 889 9000

F: +1 585 889 4030

Contact Sales

Contact Orders

Contact Service

S: +1 585 889 0200

AMBRELL B.V.

Holtersweg 1
7556 BS Hengelo
The Netherlands


Directions to Ambrell B. V. Directions

T: +31 880 150 100

F: +31 546 788 154

Contact Sales

Contact Orders

Contact Service

AMBRELL Ltd.

Unit 6, Space Business Centre
Tewkesbury Road
Cheltenham, GLOS, GL51 9FL
United Kingdom

Directions to Ambrell Ltd.Directions

T: +44 1242 514042

F: +31 546 788 154

Contact Sales

Contact Orders

Contact Service
