Shrink Fitting a Carbon Graphite Ring Insert Into an Outer Steel Band

Dec 23, 2020 1:13:50 PM / by Brett Daly posted in Shrink Fitting, induction shrink fitting




A client contacted THE LAB at Ambrell needing to heat a steel band to 1000 ºF (538 ºC) and insert a carbon graphite ring into the center of the steel band. THE LAB determined that an Ambrell EKOHEAT® 10 kW, 50-150 kHz induction heating system with a four turn, two-over-two helical coil would be optimal for this induction shrink fitting application. The frequency for this application was 132 kHz.

Read More




Shrink Fitting Automotive Turbo Charger Impeller Blades onto an Aluminum Shaft

Dec 18, 2020 3:14:21 PM / by Brett Daly posted in Shrink Fitting, automotive, induction shrink fitting




A client contacted THE LAB at Ambrell needing to heat aluminum impeller blades to 200 ºF (93 ºC) and shrink fit them onto shafts. THE LAB determined that an Ambrell EASYHEATTM 3.5 kW, 150-400 kHz induction heating system would be best for this induction shrink fitting application based on the client's requirements. The frequency for the application was determined to be 255 kHz.

Read More




Induction Shrink Fitting Steel Tubes

Nov 30, 2020 1:56:57 PM / by Brett Daly posted in Shrink Fitting, induction shrink fitting




A client contacted THE LAB at Ambrell needing to heat steel tubes to 500-1000 ºF (260-538 ºC) for a shrink fitting application. THE LAB determined that an Ambrell EASYHEATTM 7.5 kW, 150-400 kHz induction heating system would be best for this induction shrink fitting application based on the client's heating requirements. The frequency for the application was determined to be 166 kHz.

Read More




Induction Shrink Fitting a Motor Shaft and Roller

Nov 20, 2020 10:37:26 AM / by Brett Daly posted in Shrink Fitting, induction shrink fitting




A client contacted THE LAB at Ambrell needing to heat a roller assembly to shrink fit it to a motor shaft. THE LAB determined that an Ambrell EASYHEATTM 2.4 kW, 150-400 kHz induction heating system with a three-turn helical coil would be best for this induction shrink fitting application based on the client's heating requirements. The target temperature for the application was 450 ºF (232 ºC).

Read More
